• WAN port: One 10/100/1000 Mbps
  Ethernet port RJ-45
• DSL port: One RJ-11
• Ethernet port: Four 10/100/1000 Mbps
  Ethernet ports RJ-45 (8P8C)
• Wireless
  • Three internal antennas (2.4 GHz)
  • Four internal antennas (5 GHz)
• VoIP: 2 FXS ports
• USB:
  • One USB 3.0 host
  • One USB 2.0 port
• Button:
  • One power on/off button
  • One reset button
  • One WPS on/off push button
  • One WLAN on/off button
• Status LEDs indicators:
  • Power/System
  • WAN
  • Internet
  • WLAN-2.4G
  • WLAN-5G
  • WPS
  • LAN
  • Phone
• Power consumption: 12 V DC, 2.5 A

Wireless Standard

• 802.11 b/g/n/ac 2.4 GHz, data rate 600 Mbps
• 802.11 a/n/ac 5 GHz, data rate 1733 Mbps

VDSL and ADSL Compliance

• VDSL:
  • G.993.1 VDSL
  • G.993.2 VDSL2, Band 997, 998, Over POTS
  • Support VDSL profiles: 8a/b/c/d, 12a/b, 17a, and 35b
  • G.vector
• ADSL:
  • ANSI T1.413 compliant
  • G.992.1 (G.dmt)
  • G.992.2 (Splitterless, G.lite)
  • G.992.3 (ADSL2)
  • G.992.5 (ADSL2+)
  • G.INP support

Router/Bridge Features

• IEEE 801D transparent bridge & basic spanning tree
• PPPoE (RFC 2516)
• PPPoA (RFC 2364)
• MAC encapsulation routing/IPoE
• Network Address Translation (NAT)
• NAT virtual server (port forwarding)
• DHCP client/server/relay with DHCP option 43/60/61/125
• DNS proxy/dynamic DNS
• Static/Policy route
• IGMP v1, v2, v3
• IPv4/IPv6

Wireless

• Wireless Protected Setup (WPS)
• WMM
• WPA2/WPA2-PSK with TKIP & AES security type
• MU-MIMO support
• Multi SSID: up to 4

VLAN/QoS

• 802.1Q VLAN tagging/un-tagging
• Support flexible traffic classification

Firewall & Security

• Generic packet filter
• DoS attack prevention
• Parental control

USB

• File sharing
• 3G/4G dongle (By USB dongle)

Management

• Web/HTTP: 3 level log-in via SSH or Telnet
• Firmware upgrade via Web/TFTP/FTP/TR-069 RPC method
• Text based configuration
• Configuration backup/update/restore default via Web
• Configurable access control for remote management (interface and/port number)
• DSL forum TR-069, TR-098
• TR-111 and TR-181 i2
• SNMP v1, v2
• Rom-D support
• UPnP port forwarding rules on page

VoIP

• SIP (Section Initiating Protocol, RFC 3261)
• Codec: G.711 a/μ (64K), G.726 (24/32K), G.722
• G.168 echo cancellation
• Fax/modem detection and pass-through
• Voice Active Detector (VAD)
• Comfort Noise Generator (CNG)
• Dynamic jitter buffer
• DTMF detection and generation
• DTMF relay by in-band and out-of-band (RFC 2833, SIP INFO)
• SIP account (URL type included)
• On hook, off hook and flash detection
• Caller ID
• Call forwarding (No condition, busy, no answer)
• Call transferring
• Call hold/Call retrieve
• Three way conference
• Call waiting
• DNS SRV
